Multi-select a handful of photos in tonGues and they land as a single grid bubble — one caption, one timestamp, one tick, one notification — instead of a full-size bubble per image. That’s the album bubble, and it’s the feature we shipped this week on top of a messenger that, until now, was built entirely around one image per message.

The interesting part was never the grid. It was doing this without tearing up the invariant the whole codebase leans on: one message row = one media item. The rest of this post is how we layered Flutter photo albums on top of that rule instead of around it.

tonGues is a language-exchange messenger — chat, calls and live translation, Flutter on the client, FastAPI and PostgreSQL behind it. If you’re new here, start with the overview of tonGues. This post is one of a few we’re writing today, alongside the shared media gallery and the Linux desktop video work.

One row per media item — the rule we refused to break

Here’s the constraint, stated plainly. Our messages table is one row per piece of media. That single fact is load-bearing across the app:

  • Delivery reconcile is URL-based. When the upload pipeline finishes, the client matches the optimistic bubble to the real row by the uploaded file’s URL — one file, one row, one match.
  • Read receipts and reactions are per row. A thumb, a “read” tick, a count — all column-level facts on a message.
  • The offline outbox is one durable record per file. Every attachment gets its own record with its own progress and retry, so a killed app can resume each file independently.
  • Orphan cleanup scans image_url per row. A row that never got its URL is an orphan; the sweep already knows how to find it.

A naive album feature — “add an attachments table” or “stuff a JSON array of URLs into one message” — breaks all four at once. Every read path (history, search, pins, previews) would need rewriting, and the URL-based reconcile would stop matching because one row would now carry N URLs.

So we didn’t do that. We kept one row per media item and layered a group key on top of it.

Why Flutter photo albums need a group key

Three nullable columns on messages turn N independent rows into one logical album:

ALTER TABLE messages ADD COLUMN album_id    TEXT    NULL;
ALTER TABLE messages ADD COLUMN album_index INTEGER NULL;
ALTER TABLE messages ADD COLUMN album_size  INTEGER NULL;
CREATE INDEX ix_messages_album_id ON messages (album_id);

The additive-column shape matters: it’s three plain columns and an index, not a new entity.

  • album_id (indexed TEXT) is the shared group key. The client generates it at send time — a UUID-ish token — so an offline or still-uploading album is already grouped before any server round-trip. Its length is bounded on the server so a client can’t stuff the indexed column with unbounded text.
  • album_index (INTEGER, 0-based) is the only ordering authority inside a group. This one matters more than it sounds. Sibling rows upload concurrently, so their created_at timestamps can arrive out of order. If any code ever sorted a group by time, the grid would shuffle. It doesn’t — it sorts by album_index, full stop.
  • album_size (INTEGER) is the total tile count, duplicated onto every sibling on purpose. Denormalizing it means the +N overlay and the notification label render before the last sibling has uploaded, without a COUNT(*) on the hot path.

Because the columns are nullable and additive, the migration is safe to deploy ahead of the client — and the part we care about most is that album_id IS NULL renders exactly like before. Old rows, old clients, no regressions.

The anchor row

An album needs somewhere to hang the things that only make sense once per group. We call that row the anchor, and it’s simply the sibling with the lowest index (album_index == 0):

  • it carries the caption (every other sibling stores an empty content);
  • it carries the reply target, and therefore the quote preview and the “forwarded” flag;
  • it owns the footer surface — time, ticks, read count — and the reaction surface;
  • it’s the row that fires the notification.

Siblings are collapsed: no caption, no reply, no footer, no separate push. The server enforces the shape on send — album_size within range, 0 <= album_index < album_size, media present, and album_id rejected on a row with no image — so a client can’t post a half-formed group.

Grouping Flutter photo albums on the client

Grouping happens on the reader’s device, in the same pass that builds the message list’s display items. The rule is deliberately narrow: consecutive rows that share an album_id, from the same sender, with no date separator or system chip between them, collapse into one album item. Break the run — a different sender replies, a day boundary lands — and you get two albums, which is correct.

Inside the item, the tiles are ordered by album_index and never by time:

siblings
  ..sort((a, b) => (a.albumIndex ?? 0).compareTo(b.albumIndex ?? 0));

That’s the whole trick. There’s no album table, no join, no second read path. The list already built display groups for date separators and sender-name bands; an album is just one more kind of group, and it counts as a single visual unit for the gap logic between messages.

A grid that’s sized on the first frame

The premium feel of an album lives or dies on one thing: the grid must be exactly the right size before the images load. Get that wrong and the whole conversation jumps as tiles pop in.

We avoid the jump by sizing from data we already store. Every image row keeps its image_width and image_height from the moment of upload, and the album block’s aspect ratio comes from the anchor’s own dimensions (clamped so an extreme panorama can’t produce a degenerate grid). Each tile uses BoxFit.cover, so it fills its cell whatever its native ratio — the same layout model Flutter applies everywhere else. Sender and recipient both get the final layout on frame one; the images just fill in.

The layout is nothing more than a lookup from tile count:

Count Layout
1 single full bubble — the existing path, unchanged
2 two equal columns
3 one large tile left, two stacked right
4 2×2
5 two on top, three on the bottom
6 3×2
7–9 three columns; the last row is left-aligned
10+ capped at ten, with a frosted +N pill over the last tile

Two small details make it feel finished. Tiles cascade in with a short per-index fade-and-slide — and that stagger is gated on the app’s motion setting, so it’s simply zero when the user has reduced motion on. And the whole grid sits inside one shared media border, so only the outer corners are rounded and accent-bordered; the interior seams are a hairline 2 px.

Open one tile and you land in the swipe-through gallery at exactly that photo. That gallery is its own story — we wrote it up in the shared media gallery post — and albums just hand it an entry point and a starting tile.

One notification, one preview, one progress bar

An album is one logical message, so it should behave like one to the person receiving it — and this is where the fan-out bugs live.

Notifications. Exactly one push per album, fired from the anchor. A ten-photo album must not buzz ten times. The broadcast layer treats a sibling (any row with album_index > 0) as suppressed: it still emits the message event so the tile renders and gets its delivered tick, but it skips the push and the conversation-list preview entirely. The body is the same everywhere — 📷 N photos — whether it’s the push, the in-app notification list, or the friend-list preview.

Uploading. The send path is still per-file, which is what gives us per-tile progress, retry and cancel for free. For an album we generate one album_id, then loop the staged files, putting the caption and reply on the anchor only:

final albumId = newAlbumId();
final albumSize = staged.length;
for (var i = 0; i < albumSize; i++) {
  final isAnchor = i == 0;
  beginPendingUpload(
    filePath: staged[i].path,
    kind: UploadKind.image,
    content: isAnchor ? text : '',        // caption lives on the anchor
    replyToId: isAnchor ? replyId : null, // so does the reply
    albumId: albumId,
    albumIndex: i,
    albumSize: albumSize,
  );
}

On screen that becomes one thin aggregate bar across the bottom of the grid, plus a small spinner on each tile still in flight. A tile whose upload fails gets its own retry badge instead of spinning forever. Each tile is its own durable outbox record — the same “this must survive a session ending” instinct behind our Linux keyring session work — so killing the app mid-send restores the album, grouped, and resumes the tiles that hadn’t landed.

Forward keeps the group; delete takes it apart

Two actions are worth calling out because albums change their meaning.

Forward copies album_id, album_index and album_size onto every copy, so the album re-groups in the destination. Forward ten photos and the other conversation gets an album, not ten loose images.

Delete on an album removes all siblings. And there’s a tidy edge case on the other side: if an album ever drops to a single surviving row — siblings deleted one by one, say — that row clears its album_id and degrades back to a plain single image. The group key is optional, so the model simply falls back to the behaviour it had before albums existed.

What we’d do next

This phase is deliberately images-only. The model doesn’t need to change to add video tiles — album_index is media-agnostic — so mixed photo-and-video albums are a clean later step: a per-tile player, a play badge, and the chunked upload path video already has. The Linux desktop video pipeline is a good look at the machinery that would slot in. Encrypted chats stay as they are: media is already blocked there, so albums inherit the same guard and the same friendly message.

The takeaway, if there is one: a big feature doesn’t have to mean a big schema. We added three nullable columns, one convention (the anchor), and a client-side grouping rule — and kept the invariants that make delivery, receipts, reactions and cleanup work. The grid is the visible part. The three columns are the whole trick.

FAQ

Do albums need a separate API endpoint? No. An album is just a normal send with album_id, album_index and album_size attached to each row. The same REST and WebSocket send paths handle it, and the same broadcast fans it out. There’s nothing album-specific to route.

How are album tiles ordered if the uploads finish out of order? By album_index, always. Sibling rows upload concurrently and can land with timestamps in any order, which is exactly why we forbid created_at from ordering a group. The index is the only authority.

What happens if an album loses a sibling? The group stays a group while any sibling remains — a failed tile shows a retry badge rather than a hole. If the album drops all the way to one row, that row clears its album_id and renders as a normal single image.

Does this work in encrypted chats? Not yet. Media is already disabled in encrypted chats, so albums inherit the same restriction and the same user-facing message. When photo and video sending arrives there, albums will come along for free.

— the tonGues team
